STRIPPING TESTS TO DETERMINE THE QUALITY OF AGGREGATES

Stripping Tests to Determine Quality of Aggregates and Bituminous Material to be Used in Bituminous Construction

FROM time to time there creeps into the work of the Materials Engineer new terms and new fields of endeavor. The rise of the use of large amounts of bituminous material with all classes of aggregates has brought to the fore noticeable differences in their behavior. Not only is the behavior different with the same oil and different aggregates, but it is also different with the same aggregate and different oils. Thus we have been forced to cast a wandering eye upon the phenomenon which has been termed stripping.

Stripping of asphalt films apparently has been known for a long time, but what it means or how serious it is, is a ques tion that has not been fully answered. I do not presume that I can answer it here. I will, however, offer a definition. Stripping is the inability to maintain around a mineral particle a continuous film of bituminous material in the presence of water. This inability to maintain a continuous film may be due either to chemical or physical repelling effects of either one or both of the materials used.

There are several test methods that can be used to exhibit the inability of an asphalt after application to adhere to a mineral aggregate. They are as follows:

Each of these tests exhibits in its way the inability of an asphalt to adhere strongly to the mineral constituents to which it is applied. And now for a discussion of each of these tests.

1. The swell test.

The swell test is one method for determining the adhesion existing between a granular material and the applied asphaltic material. In a paper prepared for the Montana Bituminous Conference by the writer and W. W. O'Harra, Chem ist in the Arizona Highway Department, it was definitely shown that the type of oil, its processing and other characteristics (Xylene equivalent) had a great influence on the resulting swell. It was also shown that length of time of exposure to water had a very definite effect on the swell. All tests in this paper were made with SC-2 oil, but it can be assumed that heavier oils would exhibit somewhat the same tendencies. The swell test can be used either on the total ag gregate or on a portion of it. It is only necessary to determine the proper limits for each determination. At the present time the general consensus of opinion rates it as the best method available for determining the properties of a granular material when mixed with bituminous material.

The water asphalt preferential test.

Recent tests in the laboratory of the Arizona Highway Department indicate that the water asphalt preferential test is both a function of the oil as well as a function of the curing time of the oil aggregate mixture before application of the agent (water). The relationship between the oil and the resulting stripping action is not nearly so well defined as in the swell test. Dr. Hans F. Winterkorn,

By JULIAN W. POWERS

Engineer of Materials ARIZONA HIGHWAY DEPT.

(A paper delivered at the Dallas Convention, American Association of Highway Officials) In a paper prepared for this year's (1938) Montana National Bituminous Conference says: "The only definite conclusion to be derived from the use of the water-asphalt preferential test is, that mineral which goes to the oil phase is a good material, but a mineral which does not do so is not necessarily bad. To reject materials on the basis of such a test is liable to become an expensive sport."

We concur in this statement as the test is now made, but future relations based on a more adequate study and a longer time exposure of the bituminous material to the aggregate allowing possible orientation of the asphalt may result in a better correlation to actual field results. This test is applicable only to the minus No. 200 sieve material.

The stripping test, as outlined by the B. P. R.

In this case bituminous material to be used on the project is the oil to be used in the test. A curing period is allowed after which the mixture is agitated with water for a fifteen-minute period, and the results estimated and reported as no stripping, slight stripping, and a bad stripping. The results are not easy to estimate and are influenced appreciably by the temperature of the liquid. In order to get a more precise method of estimating the stripping we have used mixtures of methanol and water. Methanol itself does not tend to strip any of the materials we have used with it to date. This method holds some promise as it will show in most cases a definite point at which materials will, or will not strip. In the high ranges of methanol concentration there is a slight solution of the asphalt by the methanol which may cause errors in the test procedure in that range. This percentage is in the neighborhood of 90% methanol and 10% water. It is probable in this range that materials will not be suitable and this need not be a concern.

In order to test the effectiveness of this method to differentiate between materials we selected several uniform materials, crushed, screened, and washed them, and added SC-6 road oil. The mixes were then cured and agitated as called for by the Bureau of Pubile Roads with both water and water methanol solutions of varying proportions. The results of these tests on uniform materials are as follows:

8. Gneiss (Pegmatitic) 85 9. Silicified Limestone 0 (Shows some slight stripping up to 25% methanol) Of these materials, chert, basalt, and mixtures of basalt porphyry and arkose have been used on work in this State with nearly all classes of oil. So far as can be determined the roads are fairly satisfactory. It might be noted, however, that those constucted with chert aggregates do exhibit some stripping as evidenced by return of the surface to the natural color in a very short time. Until more data is accumulated by this method, or methods patterned after it, using possibly other miscible agents with water, and the ultimate correlation of such methods, no limits should be set for satisfactory aggregates.

There has been a good deal of effort put forth by many investigators to use other agencies to correct the tendency to strip. Particularly so is this true of Dr. Winterkorn. In the paper referred to above, he suggests that certain primers, not necessarily of an asphaltic type, may aid in preventing stripping. Whether they would be cheaper than other aggregate sources is for the individual to determine. It should, however, be demonstrated first that such primers are permanent. Heating will, in many cases, correct stripping faults as was evidenced by heating quartz (a material which strips readily) to a dull red heat after which it did not evidence any stripping.

How serious is stripping in the completed roadway?

It is my observation that for light oils it is serious because rising waters in the base will cause migration of the oil upward, enriching the top, with the likelihood of instability as exhibited by corrugations.

In the heavier oil, I am not so sure that it makes an appreciable difference providing the material (mineral) is amply protected either by densification of the mix or a proper seal coat, using an aggregate that does not strip.

On a recent trip in Texas with W. H. Wood, Materials Engineer of the Texas Highway Department, we examined one place on a section of inverted penetration in which there were particles which had stripped to the extent of having practically no adhering asphalt; yet this road was in excellent condition and seemed to be none the worse for stripped particles.

In preparing this article for discussion, I have tried to outline briefly some of the efforts that have been made to solve the stripping problem from the laboratory standpoint. Much apparently is left to be desired in both the tests and the materials we have to work with, especially the asphaltic binders In closing I should like to commend to you the paper by Mr. E. F. Kelley, Chief of Division of Tests, B. P. R. in the 1937 Proceedings of the Highway Research Board, and the paper prepared for the Montana National Bituminous Conference at Edgewater Park, Mississippi, by Dr. Hans F. Winterkorn of the Univers. ity of Missouri, both on the subject of adhesion of bitumen to mineral aggregates.
