Ed Hansberger of Yuma heats ten apart ments, right, with this flat-plate collector of his own design. Basically similar collee tors are planned for Paolo Soleri's "city energized for the sun," below still in the design stages.

WHAT'S NEW from page 11

For scientists themselves. For it is not true at all that there is nothing new under the sun.

Before the availability of natural gas and cheap electric power, the solar water heater was a commonplace. In Arizona, California, Florida, and other states, simple solar collectors with black-painted storage tanks were mounted on countless roofs to tap the sun for domestic water for bathing and other domestic uses. With cheap gas and electric energy, however, users turned away from such homely heaters. Only in recent years, as natural gas supplies have waned and even disappeared in some areas, and as electricity began to cost more, has the lowly solar hot water heater returned.

While solar water heaters are much used in Israel, Japan, and Australia, America presently is not a major user. Price is a big factor, and few homeowners or landlords appreciate the much greater initial cost. However, as gas is increasingly being cut off for new construction, and electricity climbs in price, solar installations are beginning to be made. Some people have built and installed their own, for a solar heater is a very simple project.

The Tucson Society of Professional Engineers recently reported that solar water heating is economical now in our state. Recommended is a collector area of about 80 square feet, and a large storage tank of 100 gallons to provide ample hot water the year around, over the occasional stretches of several days when very little solar energy is available.

Arizona is a popular setting for swimming pools, and solar heat can make pools more effective. It seems a shame to build an expensive pool and use it for only four months of the year but that is what most Arizonans do. The reason is financial, for heating with natural gas can cost a hundred dollars or more a month during winter. Electric heaters are prohibitive in operating cost for all but the wealthy. So pool owners are turning to solar heaters by the hundreds. The sun is matched well to pool heating because there is no need to provide very hot water. While domestic hot water must be in the range of 150 degrees or so, pools need to be warmed only to about 80 degrees, and some polar bears can survive in 75 degrees. Thus a very simple solar collector can do the job and operate efficiently sometimes even without glazing over the collector, or insulation under and around it.

To aid the solar heater in its task, some pool owners adopt methods of keeping heat in the pool after the sun has put it there. Incidentally, the pool itself is a good solar heat collector, if it is not shaded during the day by trees or houses. A sheet of plastic laid right on the pool works wonders, and can add as much heat to the pool as a solar heater. A heater about half the area of the pool can keep the water about 10 degrees above normal. Adding plastic contributes perhaps another 10 degrees, giving a temperature gain of 20 degrees over normal. Thus the pool can be comfortable for swimming in all but December, January and February.

With a solar water heater, and another to keep the pool warm, the home owner begins to wonder why not heat his house as well? Why not indeed, for there are now perhaps 200 such installations in our country, with new starts coming on so fast that no one can really keep up with them accurately.

Basically there are two methods to heat a house with sunshine. One uses water or some other liquid as the circulating and storage medium. The other uses air to gather heat from the collector. Both approaches work well, and generally the choice is made on the basis of environmental conditions prevailing in the area.

It is not surprising that the noted Paolo Soleri, whose "arcology" is flowering in the city of Arcosanti 60 miles north of Phoenix, should appreciate the use of solar energy for heat-ing ing a structure. Soleri speaks of a "city energized by the sun," and his Teilhard de Chardin Cloister to be built at Arcosanti embodies this concept.

The Cloister will be a series of spaces and shelters clustered around an apse 76 feet in diameter. This amphitheater is itself a "sun-machine" since it is cave-like and open toward the South. Stepping down in front of the amphitheater, and absorbing solar radiation, is a greenhouse garden which will feed warmed air to the amphitheater during the winter months.

The basilicas, two structures for exhibition on the east and west of the central amphitheater, present a south-facing wall over 200 feet in length. This wall curves outward and will be a good receptor of solar heat from the low winter sun yet also a good self-shading structure under the high summer sun. Atop the curved wall will be a solar collector measuring 9 feet by 200 feet. Air warmed by it will be blown into the exhibition space in the basilicas and recirculated to the solar collectors through an air chamber built along the walls.

Further helping to make the Teilhard de Chardin Cloister self-sufficient and less dependent on conventional energy sources is the fact that its north side will be cut into a cliff to provide a maximum of insulation. Terrace gardens atop the basilicas and the amphitheater will also provide insulation against winter cold and summer heat.

Most people can understand how the sun can heat a house - it does such an excellent job on a closed automobile in summer! Solar refrigeration, however, seems like solar magic to all but the refrigeration engineers who comprehend the absorption refrigeration cycle. This clever system needs no mechanical compressor, substituting an absorber that is actu-ated by heat which can be solar heat.Electrical wizard Michael Faraday invented absorption refrigeration quite by accident while trying to do something else with ammonia and water. He came back to find ice in one of the vessels used in his experiment. One of the results was the gas refrigerator of the Servel type with its small gas flame replacing a conventional compressor motor. Ice-making plants use ammonia-water absorption refrigeration equipment, and many buildings are cooled by large tonnage absorption units. Now Arkla Industries is manufacturing 3-ton units for use with solar energy systems.

The Tucson Society of Professional Engineers, who reported that solar water heating was economical right now, were less encouraging about home heating with sunshine unless it could be combined with summer refrigeration, using the same rooftop collector. This dream scheme is functioning now in many installations, with the hot summer sun providing the energy to refrigerate homes and buildings. The beauty of this approach is that when the cooling load is greatest, there is the greatest amount of solar energy to handle it!

In addition to the many solar homes under construction or planned for Arizona there are more ambitious projects including apartments, office buildings, medical centers, schools, and industrial plants.

Very large programs are envisioned to demonstrate that we do indeed possess now the technology needed to provide heat and service hot water to homes, apartments, and institutions throughout much of the nation.

The ultimate goal of Federal solar energy legislation is something that the experts call "technology transfer." This means moving the know-how from laboratories of the Solar Energy Research Institute into the market place and into the homes and other buildings of the American public. Here is the proof of the pudding, the pay-off in energy benefits to justify the expenditure of government dollars. Already we can begin to see glimpses of this pay-off in useful applications of solar energy in several areas.
